GD6912 bearing axial rigidity measuring instrument

  •

    ZYS bearing axial rigidity measuring instrument is specialized instrument, it can give a true reflection of the bearing rigidity.


    Features:
    • Precision axial loading device is used in the system, it can axial load continuously and steadily. The loading range is 50~500N stepless adjustment.
    • Precision spindle have superior motion accuracy, rigidity and steadily under certain load.
    • The circuitry has strong anti-jamming ability, good steadily and fast response speed.
    • The test software calculates rigidity, mean rigidity according to the sampling result of force sensor and inductive displacement sensor. It also fits a rigidity curve of each point’s rigidity automatically.

    Technical Specification

    Bearing dimensions and        Bearing bore diameterφ10~60mm
    measurement range:            outside diameterφ15~100mm
    Axial load:                   50~500N, stepless adjustment
    Load measurement precision:   ≤±1﹪F·S
    Displacement range:           300µm
    Displacement resolution:      0.1µm
    Displacement precision:      ±(0.5+0.01T) µm (T is actual
    measuring displacement value)
    Rigidity error:              ±5﹪
